| Printer Specifications | |
|---|---|
| Printer Type | Label |
| Printer technology | Supports both thermal and direct transfer |
| Barcode Scanner Information | |
| Barcode Scanner Type | Barcode Printer |
| General Information | |
| Warranty | 1Year |
Specifications
| MECHANICAL | |
| Dimensions (L x W x H) | 10.74 in x 7.8 in x 6.6 in (273 mm x 198 mm x 168 mm) |
| Weight | 4.5 lbs (2.04 kg) |
| MEDIA | |
| Maximum Media Diameter | 5.0 in (127 mm) |
| Media Core Sizes | 1 in (25.4 mm); 1.5 in (38.1 mm) |
| Media Width | 1 in to 4.5 in (25.4 mm to 114 mm) |
| Minimum Label Length | 0.37 in (9.6 mm) |
| Maximum Print Length | 190 in (4826 mm) for 203dpi, 85 in (2159 mm) for 300dpi |
| RIBBON | |
| Ribbon Support | Coated side out |
| Maximum Ribbon Diameter | 2.7 in (68 mm) |
| Ribbon Core Sizes | 0.5 in |
| Ribbon Width | 1 in to 4.3 in (25.4 mm to 110 mm) |
| Maximum Ribbon Length | 300 m @ 1 in core; 74 m @ 0.5 in core |
| PRINTING | |
| Print Resolution | 203 dpi (8 dots/mm) |
| Default Print Speed | 100 mm/s (4.0 ips) |
| Maximum Print Speed | 203 dpi: 6 ips |
| Maximum Print Width | 4.25 in (108 mm) |
| COMMUNICATIONS | |
| Standard Interfaces | USB Device, USB Host, factory installed Internal Ethernet |
| Options | USB to serial cable Wi-Fi 5 & Bluetooth® 5.0 module |
| Protocols | TCP/IP suite (TCP, UDP, M, IGMP), LPR/ LPD, Telnet/SSH, FTP/SFTP, BOOTP, DHCP, HTTP/HTTPS, SMTP Supports IPv4 and IPv6 |
| USER INTERFACE | |
| Display | 1 Feed Button, 1 ECO Button and LED |
| Web Page Languages | English (Default), Simplified Chinese, Traditional Chinese, German, French, Italian, Korean, Portuguese, Russian, Spanish, Japanese, Thai |
| GRAPHICS AND BARCODES | |
| Native Graphic Formats | 1-bit BMP, GIF, PCX, PNG |
| Barcode Symbologies | Supports all major 1D and 2D symbologies including: Aztec, Code 16K, Code 49, Data Matrix, Dot Code, EAN-8, EAN-13, UCC 128, Grid Matrix, HIBC 39, HIBC 128, MaxiCode, MSI, PDF417, Micro PDF417, Planet, Plessey, Postnet, QR-Code, RSS-14 (variations) |
| SOFTWARE | |
| Printer Command Languages | Direct Protocol (DP), DPL, ZSim2 (ZPL II), ESim (EPL), XML enabled for SAP® AII and Oracle® WMS |
| Drivers | Inter Driver Windows® printer driver, CUPS driver for Linux, Honeywell Device Types for SAP, Honeywell label design and print package, BarTender® |
| Character Sets | Supports various character sets including English, Extended Latin, Arabic, Baltic, Cyrillic, Greek, Hebrew, Thai, Turkish, Vietnamese, etc. |
| ENVIRONMENTAL | |
| Operating Temperature | +41°F to +104°F (+5°C to +40°C) @ 10 to 80% RH non-condensing |
| Storage Temperature | -40°F to +140°F (-40°C to +60°C) @ 10 to 90% RH |
| ELECTRICAL | |
| Input | 90~264V voltage |
| Output | 24V DC, 2.5 A |
| MEMORY | |
| Standard | 128 MB Flash, 128 MB SDRAM |
| ACCESSORY OPTIONS | |
| Cutter | |
| Peel-off | |
| Roller | |
| APPROVALS | |
| Regulatory | CE, C TUV US, FCC, IC |
| Safety | CB |
| Europe | EN 62368-1 |
| Other Countries | IEC 62368-1 |
| EMC | Europe EMC Directive, EN55032 CLASS A+, EN55035 |
